Max platform height
3m/3.9m/4.8m
3-7m Mini Scissor Lift
INTERESTED IN OUR PRODUCTS?
contact us
Semi Electric Mini Scissor Lift
- Specs Table
|
Model Type |
|
SJY5.0 |
SJY5.9 |
SJY6.8 |
|
Maximum platform height |
mm |
3000 |
3900 |
4800 |
|
Minimum platform height |
mm |
630 |
700 |
830 |
|
Lifting capacity |
kg |
300 |
300 |
300 |
|
Platform size |
mm |
1170×600 |
1170×600 |
1170×600 |
|
Lifting Time |
sec |
33 |
40 |
40 |
|
Descent time |
sec |
30 |
30 |
30 |
|
Lifting Motor |
v/kw |
12/0.8 |
12/0.8 |
12/0.8 |
|
Rising/Falling Speed |
sec |
33/30 |
33/30 |
33/30 |
|
Battery |
V/Ah |
12/60 |
12/60 |
12/60 |
|
Charger |
V/A |
12/10 |
12/10 |
12/10 |
|
Whole Length |
mm |
1300 |
1300 |
1300 |
|
Whole Width |
mm |
740 |
740 |
740 |
|
Whole Height |
mm |
1650 |
1750 |
1880 |
|
Overall Net Weight |
kg |
360 |
420 |
475 |
- Photos Display
- Our Team
FAQ
| 1: How to place an order? | |
| Answer: Please tell us your detailed requirements (including your product materials, product dimensions and product weight), and we will send you detailed parameters and quotations as soon as possible. | |
|
|
| Answer: It depends on your requirements of the equipment and shipment terms (FOB, CIF, CFR, EXW, etc.) | |
| 3: How to make the payment? | |
| Answer: We accept wire transfer; letter of credit; Alibaba trade guarantee. | |
| 4: What is the lead time? | |
| Answer: For the standard product, the delivery time is 7 days. For customized orders with no stock, we need to determine the delivery time according to the situation, usually it’s 20-30days. If you need urgent items, please contact us. | |
| 5: About the warranty | |
| Answer: Our machines enjoy a complete 1-year warranty. Lifelong technical support via email or video. | |
| 6: About the guarantee | |
| Alibaba will protect your order. We are Alibaba verified manufacture. We have Alibaba trade guarantee. | |
| 7: Mode of transportation | |
| Answer: You can choose sea, air, rail transportation. |
